Introduction:
PCR340 is a simple- to- use device applying dual 125Khz and 13.56Mhz RFID technology to read the unique serial number of the RFID card. It is good to be used for the system access logon/logoff key and the system operator identification, such as POS system logon/logoff and operator identification /authorization with RFID card. PCR340 is a perfect system logon key which can protect the system and prevent the unauthorized people from using the system.
Features:
·Read either 125 Khz or 13.56Mhz frequency cards
·Designed with RS232 or PS/2 or USB interface
·Read unique serial number (UID) of the RFID card
·System Logon/Logoff
·Verify ID code for the system operator identification
In addition to the ID code data, prefix or/and postfix characters can be set
·Cradle design to accept RFID card for the application as below:
≯System is workable when the registered card is sitting on the cradle
≯System is not workable when the registered card is removed from the cradle.
Applications:
·Systems security
·Personal Identification
·POS Systems
·Access Systems Logon/Logoff key
·Personal ID systems
·Automatic data logging
Specifications:
Ordering information:
·PCR340 - RS232 interface
·PCR340 - PS2 interface
·PCR340 - USB interface
※ Specification is subject to change without notice.

PCR340 is a simple- to- use device applying dual 125Khz and 13.56Mhz RFID technology to read the unique serial number of the RFID card. It is good to be used for the system access logon/logoff key and the system operator identification, such as POS system logon/logoff and operator identification /authorization with RFID card. PCR340 is a perfect system logon key which can protect the system and prevent the unauthorized people from using the system.
Features:
·Read either 125 Khz or 13.56Mhz frequency cards
·Designed with RS232 or PS/2 or USB interface
·Read unique serial number (UID) of the RFID card
·System Logon/Logoff
·Verify ID code for the system operator identification
In addition to the ID code data, prefix or/and postfix characters can be set
·Cradle design to accept RFID card for the application as below:
≯System is workable when the registered card is sitting on the cradle
≯System is not workable when the registered card is removed from the cradle.
Applications:
·Systems security
·Personal Identification
·POS Systems
·Access Systems Logon/Logoff key
·Personal ID systems
·Automatic data logging
Specifications:
Specification /Model | PCR340 | ||
Interface | RS232 | PS2 | USB |
Reading Frequency | 125Khz, 13.56Mhz | ||
Baud rate | 19200,14400,9600,4800,2400 bps | ||
Card types | EM compatible64 bits, ASK Manchester coding, ISO 14443A Mifare® MF1 1K&4K / Ultralight / DESFire; Read only (for unique serial number/ unique identifier) | ||
Reading distance | 80 mm / 125KHz 40 mm / 13.56MHz | ||
Power requirement | DC 5V, Stand by 70mA | ||
Safety Certificate | CE / FCC | ||
Dimensions | L120 x W86 x H42 mm | ||
Environment | Operation Temperature: -0 ~ 50 Deg. C Storage Temperature: -10 ~ 60 Deg C Humidity: 10 ~ 90% |
Ordering information:
·PCR340 - RS232 interface
·PCR340 - PS2 interface
·PCR340 - USB interface
※ Specification is subject to change without notice.
