Technical Specifications:
Item NO.TM-8012
Description: 12 SPINDLE WINDING MACHINE
Number of spindles: 12
Control system: AC Servo Motor
Data storage: 1GB CF Card
Tensioner: Mechanical
Spindle Pitch: 80 mm
Max.Bobbin Diagonal: 60 mm Bobbin width under 55mm
Max.Width of winding: 95 mm
Winding Speed: 9000 RPM
Winding Direction: CW/CCW
Spindle Stop Accuracy: +/-0.225 degrees
(AWG/mm) Wire Range: AWG48~24/0.03~0.5mm
Maximum Travel Distance X: 100 mm
Maximum Travel Distance Y: 100 mm
Maximum Travel Distance Z: 80 mm
XYZ Axes Increment(Step): 0.02mm (mechanical),0.001 mm (program)
Wire Wrapping Angle: 0°/90°
Maximum Wrapping Speed: 200mm/sec
Power source: 1¢ AC 220V,50/60 HZ
Consumed power: 5KW
Air Pressure Supply Required: 5-6 KGS/cm2(=0.5-0.6MPA)
Machine Dimension (Include screen): 190(L)X 120(W)x 150 (H)cm
Machine Dimension (Include screen and tensioner case): 190(L)x235(W)x 160(H)cm
Machine weight: 880KGS
Options:
Wire Twister(Wire diameter under 0.05mm)
Automatic Loading & Unloading
Cutter (Wire Diameter: Over 0.40mm)
Knife (Wire Diameter: Over 0.15mm)
Wire polisher
Remarks:
Spindle: 12
Maximum twisting length: 375mm
Number of Wire Strands: 1.3.5.7.9.......Programmable
Maximum twisting speed: 5000 RPM
Suit Coil: 50、60 synchronous motor
Application: Mahjong machine， Automatic Idle Speed (AIS) Motor

Features:

1. Our machine use PLC to control,you can accurately adjust winding speed of automatic winding machine.
2. Wire is closely and neatly.
3. Can save several programs in machine.
4. A person's labor force can complete the work more than many people,greatly improving production capacity.
5. Worker can achieve good job after a simple training.
6. Can wire more type of bobbin,you can accurately and conveniently adjust the winding speed of automatic winding machine.
