Terry knitting machine is SUNDA most sophisticated model.
It has made a magnificent sales records of more than 30,000 sets sold worldwide and had won the best Terry Award.

Thanks to the pervasive use of Polar Fleece fabrics with its advantages of light, quick dry, stretchable, and warm.
Besides above, Sun Da Terry machines can produce best loop effect and perfect anti-pilling texture.

■ Sinker: Pile height 1.2mm-5.0mm*
■ Complicated PK Cams: design in Raising cam, Stitch cam, Tuck cam and Welt cams are available.
■ Multiple needle guidance and sinker guidance
* 0mm pile height is available

Since 1976, Sun Da has began to R&D Terry knitting machine for more and more extensive and sophisticated fleece requirement.
We have its fame throughout the past years and will move forward for more demanding customer’s needs.

Your right choice of Polar Fleece - Sunda Terry knitting machine SD-60.

Machine Features:
■ WIDE RANGE OF SINKER PILE HEIGHT:
To meet customer’s individual needs, there are many different type of sinker to knit terry fabrics for different pile heights from 1.2 to 5.0mm. It will boost the return on investment (ROI) for the machine.

■ WIDE RANGE OF PK CAM DESIGNS:
Raising cam, Stitch cam, Tuck cam and Welt cams are available to make as many designs as possible.
Terry PK fabrics such as Scottish roving cloth, bricks, and etc can produce by this machine.

■ SPANDEX AVAILABLE: (Option)
Spandex device can surely add on the machine to produce high quality elastic polar fleece fabrics without any problem.

■ VERSATILE CONVERT FUNCTION:
By replacing the conversion kit, SD-60 can convert to Single Jersey, Three Thread Fleece, and Velour machine.
SD-60 creates a best platform for you to make as many variables as possible.

Conversion Kit:


Specification:

	SD-60 30"X24GX60F	SD-3F 30"X24GX90F	SD-FL 30"X20GX90F	SD-48 30"X24GX48F
Yarn Carrier & Ring		●	●	●
Sinker cam		●	●	●
Sinker		●	●	●
Cylinder cam		●	●	●
Cylinder cam box		●		●
Cylinder	※	●	●
Cam box Ring				●

※    If use WO110.52 G006, Terry cylinder is compatible with Single jersey cylinder and same needle number do not need to change cylinder ※    If use WO110.49 G0010, Terry cylinder can not use for Single jersey cylinder.



Fabrics:
Terry knitting fabrics can be used in raising, brushing, shearing, and embossing after-finishing process to make single side polar fleece or double side polar fleece.  PK polar fleece such as flocking fleece, Scottish fleece and etc.

Applications:
Hoodies, gym clothes, high performance outdoor wear, and any other light or stretchable warm clothes.

Specification:

Specification	Cylinder Dia.	Gauge	Feeder/INCH
SD-60	26"~46"	14G~32G	2F
SD-60PK	26"~46"	14G~24G	2F
SD-60PKDC2	26"~46"	14G~24G	2F
SD-60CG	26"~46"	8G~12G	1.6F
SD-60CG2	26"~46"	5G~7G	1.2F
SD-60CG3	26"~46"	3G~4G	30" for 24F

[ SD-60 ]
Equipped with 1 track cam on dial and cylinder.
[ SD-60PK ]
Equipped with 1 track  cams on dial and 2 tracks on cylinder.
[ SD-60PKDC2 ]
Equipped with 2 tracks  cams on dial and 2 tracks on cylinder. *
[ SD-60CG ]
Coarse gauge Terry equipped with 1 track cam on dial and cylinder.**
*    Sunda SD-60 Terry knitting machine Maximum 2 track on dial and 4 track on cylinder
**   Beyond above specification, welcome to contact us for customization.

Machine Size:

Diameter	Net Weight (kgs)	Gross Weight (kgs)	Size of Wooden Case (cm)
16"~22"	1600	1800	200x168x200
24"~30"	2000	2200	220x210x207
32"~36"	2400	2600	220x220x207
38"~40"	2800	3000	250x220x207
