Terry Coarse Gauge knitting machine is the extension model of successful SD-60 Terry knitting machine.
From 3 Gauge to 12 Gauge, one track or multi-track needle guidance options, the SD-60CG machine versatility is beyond your imagination.

Versatile Options:
■ Design: Complicated PK design in Raising cam, Stitch cam, Tuck cam and Welt cams.
■ Yarn: twisted yarn, multi-ply yarn, compound yarn, metal yarn, blended yarn and etc to make as many application as you want.

Your right choice of Polar Fleece - Sunda Terry knitting machine SD-60CG.

Machine Features:
■ WIDE RANGE OF PK CAM DESIGNS:
Raising cam, Stitch cam, Tuck cam and Welt cams are available to make as many designs as possible.
Terry PK fabrics such as Scottish roving cloth, houndstooth, and etc can produce by this machine.

■ SPANDEX AVAILABLE: (Option)
Spandex device can surely add on the machine to produce high quality elastic polar fleece fabrics without any problem.

■  VERSATILE CONVERT FUNCTION:
By replacing the conversion kit, SD-60 can convert to Single Jersey, Three Thread Fleece, and Velour machine.
SD-60 creates a best platform for you to make as many variables as possible.

Conversion Kit:



	SD-60CG 30"X7GX48F	SD-FLCG 30"X7GX48F	SD-CG 30"X7GX48F
Yarn Carrier & Ring		●	●
Sinker cam		●	●
Sinker		●	●
Cylinder cam		●	●
Cylinder cam box
Cylinder	*	*	*
Cam box Ring

*If use same needle, then do not need to change cylinder when convert.



Fabrics:
Terry knitting fabrics can be used in raising, brushing, shearing, and embossing after-finishing process to make single side polar fleece or double side polar fleece.  PK polar fleece such as flocking fleece, Scottish fleece and etc.

Applications:
Hoodies, gym clothes, high performance outdoor wear, and any other light or stretchable warm clothes.

Specification:

Specification	Cylinder Dia.	Gauge	Feeder/INCH
SD-60CG	26"~46"	8G~12G	1.6F
SD-60CG2	26"~46"	5G~7G	1.2F
SD-60CG3	26"~46"	3G~4G	30" for 24F

[SD-60CG]
Coarse gauge Terry equipped with 1 track cam on dial and cylinder*

*    Sunda SD-60CG Terry knitting machine Maximum 2 track on dial and 4 track on cylinder**
**   Beyond above specification, welcome to contact us for customization.
