Advanced tungsten alloy tool steel
Widely used for making punching die, stamping die, bending die and finishing die with thickness less than 8mm,also used for making gauges, measuring tools, woodworking tools and lathe thimbles, guide bushings, thimbles, dies, needles, etc.
1.Ingredient:
2.Equivalent steel:
3.Heat treatment:
4.Mechanical properties:
5.Origin Place:Taiwan ,China,Korea
Widely used for making punching die, stamping die, bending die and finishing die with thickness less than 8mm,also used for making gauges, measuring tools, woodworking tools and lathe thimbles, guide bushings, thimbles, dies, needles, etc.
1.Ingredient:
Steel Grade | C | Si | Mn | P | S | Cr | W |
---|---|---|---|---|---|---|---|
SKS3 | 0.90-1.00 | 0.15-0.35 | 0.90-1.20 | <0.025 | <0.010 | 0.50-1.00 | 0.50-1.00 |
2.Equivalent steel:
Equivalent steel | JIS | AISI | DIN | GB |
---|---|---|---|---|
SKS3 | O1 | 100MnCrW4 | 9CrWMn |
3.Heat treatment:
Normalization | Annealing | Quenching | Tempering |
---|---|---|---|
750-800 Furnace Cooling | 550-650 Pre-heating 820-870 Oil Cooling |
150-200 Air Cooling |
4.Mechanical properties:
Tensile Strength (kgf/mm²) | Hardness (HBC) |
---|---|
140 | 60 |
5.Origin Place:Taiwan ,China,Korea
