Carbon steel
The most widely used steel for industrial use, such as general connecting rods, joints, crankshafts, screws, etc.
1.Ingredient:
2.Equivalent steel:
3.Heat treatment:
4.Mechanical properties:
5.Origin Place:Taiwan ,China,Korea
The most widely used steel for industrial use, such as general connecting rods, joints, crankshafts, screws, etc.
1.Ingredient:
Steel Grade | C | Si | Mn | P | S |
---|---|---|---|---|---|
S45C | 0.42-0.48 | 0.15-0.35 | 0.60-0.90 | <0.030 | <0.035 |
2.Equivalent steel:
Equivalent steel | JIS | AISI | DIN | GB |
---|---|---|---|---|
S45C | SAE1045 | 1.0503 | 45 |
3.Heat treatment:
Normalization | Annealing | Quenching | Tempering |
---|---|---|---|
800-870 Air cooling | 810 Furnace cooling | 820-870 Oil cooling | 550-650 Quickly cooling |
4.Mechanical properties:
Yielding Strength (kgf/mm²) | Tensile Strength (kgf/mm²) | Elongation (%) | Section reduction (%) | Charpy | Hardness (HBW) |
---|---|---|---|---|---|
>70 | >50 | >17 | >45 | >78 | 201~269 |
5.Origin Place:Taiwan ,China,Korea
