Read Write Module - RWM600A

Read Write Module

Item No.: RWM600A
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 8F, No. 31 Lane 169, Kang-Ning Street, Hsi-Chih Dist
TEL: +886-2-26954214
Fax: +886-2-26954213
Online Showroom: 84 Products
Smart Label Read/Write Module

Introduction:
RWM600A is an ISO15693 read/write module, which works with smart labels, the read/write module has a read/write feature, depends on the size of antenna, the optimum read distance can be up to 200mm.

RWM600A read transponders with an operating frequency of 13.56Mhz (e.g. Tag-It ®HF-I, I-CODE SLI, LRI512, my-d vicinity…etc …etc.), and it is a small size module with DIP28 pin package.

RWM600A is a best choice for system integrator to install into other devices, such as printers, terminals and handheld devices.


Features:

·Compact size to be integrated
·ISO/IEC 15693 compatible
·Small Reader module (DIP28)
·Support all ISO/IEC 15693 compliant smart labels (Tag-It ®HF-I, I-CODE SLI, LRI512, my-d vicinity…etc)
·Operate time <24ms per one label
·Reading distance up to 200mm (0.2W) with an ideal design antenna conditions
·10 Programmable I/O, IRQ, D/O for OEM
·In-System Programmable firmware for OEM


Applications:
·EPC (Electronic Product Code) supply Chain
·EPC for retail system
·Logistics system
·Express Parcel Management
·Product Authentication
·Access control / Time recorder
·Ticketing
·Smart label printer and encoder

Specifications:
Power Requirements5 VDC Stand by: 70mA, Transmit:<80mA ※ A linear regulator is recommended
InterfaceUART, TTL: 19200,n,8,1
Card typeTag-It ®HF-I, I-CODE SLI, LRI512, my-d vicinity…etc
Maximum reading distanceUp to 200 mm with an ideal antenna conditions     (0.2 Watt output)
Frequency13.56 MHz standard
RF Modulation/Subcarrier100% FM
RF ProtocolISO/IEC15693
Operate time<24ms per one label
Dimensions39 (L) x 21 (W) x 11.6(D) mm
EnvironmentOperating temperature -10°C ~ +60°C Operating relative humidity 10~90%

Ordering information:
RWM600A: RWM600A Reader module

RWM600ASK: Smart Development Kit included RWM600A + RS232 cable + SDK CD + Tag-It HF-I x 3 pcs
※ Specification is subject to change without notice.
