■ Product Features
1. UV molding surface with self-study after high refractive index coating, suitable for the system to make the brightness enhancement film.
2. hardened surface low yield, not to damage the substrate.
3. Has the strength and toughness, pulling prone to breaking.

■  Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Clear yellow
4.Solid content: approach 100%
5.Viscosity (26 ℃): 680 ± 80 cps
6.Liquid refractive index: 1.572 ± 0.01
7.Resin gravity: 1.08 g / cm3
8.The glass transition temperature (Tg): - 11 ℃

■  Hardening conditions
1. The resin-coated at a thickness of 30μm, it is recommended UV accumulated energy greater than 350 mj / cm2.
Version 2 rounds Recommended operating temperature 40 45 ℃ production rate does not exceed 12M / min

 ■  Finished properties (Sunbeam C87H 100 μm PET)
1.Coating thickness: 30μm (dry film thickness)
2.Haze%: Less than 2.0
3.100 grid knives (after molding): 5B
