■ Product Features
1. UV molded surface after a review of the self-study.
2. hardened surface low yield, not to damage the substrate.
3. Has the strength and toughness, pulling prone to breaking.

■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Clear yellow
4.Solid content: approach 100%
5.Viscosity (26 ℃): 150 ± 80 cps
6.Liquid refractive index: 1.54 ± 0.005
7.Resin gravity: 1.12 g / cm3
8.A glass transition temperature (Tg): -12 ℃

■  Hardening conditions
1. The resin-coated at a thickness of 25μm, it is recommended UV accumulated energy greater than 350 mj / cm2.
2. It is recommended to use a solvent-free process.
3. Recommends wheel with operating temperature: 45 ~ 50 ℃, the production rate: less than 10M / min.

■ Finished properties (Sunbeam C87H 125 μm PET)
1.Coating thickness: 25 mm (dry film thickness)
2.Refractive index (RI) at a wavelength of 633nm: 1.562
3.Haze: less than 1.0%
4.100 grid knives (after molding): 5B
5.100 grid knives (ring measured after 500 hours **): 5B
