QCM 8
Item No.: | QCM-8 |
Supplier Details
Country: Taiwan
City: Tainan City 710
Address: No. 342, Zhongzheng S. Rd., Yongkang Dist.
TEL: +886-6-2539799
Fax: +886-6-2435785
Online Showroom:
26 Products
SANYO cold work tool steel
is a high-carbon high-chromium alloy steel with extremely high hardness, which is suitable for toughness and has a tempering hardening effect. It is a representative of multi-purposes such as stamping dies and plastic dies. It surpasses SKD11 in hardness, toughness, fatigue strength and wear resistance, greatly extending the life of the mold.
1.Ingredient: Manufacturer's exclusive secret recipe
2.Equivalent steel:
3.Heat treatment:
4.Mechanical properties:
5.Origin Place:Japan
is a high-carbon high-chromium alloy steel with extremely high hardness, which is suitable for toughness and has a tempering hardening effect. It is a representative of multi-purposes such as stamping dies and plastic dies. It surpasses SKD11 in hardness, toughness, fatigue strength and wear resistance, greatly extending the life of the mold.
1.Ingredient: Manufacturer's exclusive secret recipe
2.Equivalent steel:
Equivalent steel | JIS | AISI | DIN | GB |
---|---|---|---|---|
SKD11 improved | D2 improved |
3.Heat treatment:
Normalization | Annealing | Quenching | Tempering |
---|---|---|---|
830-880 Slow Cooling | 1000-1050 Air Cooling | 500-550 Air Cooling 2 times |
4.Mechanical properties:
Yielding Strength (kgf/mm²) | Tensile Strength (kgf/mm²) | Elongation (%) | Section reduction (%) | Charpy | Hardness (HRC) |
---|---|---|---|---|---|
55~62 |
