PPHE Grey Plate
Item No.: | TOIL-730 |
Supplier Details
Country: Taiwan
State: Taiwan
City: Kaohsiung
Address: No.16,Tzu-Chi Rd.,FengShan District
TEL: +886-7-7517106
Fax: +886-7-7254797
Online Showroom:
57 Products
<Advantages>
1. Smooth plate surface
2. Superior flatness
3. High rigidity
4. Compressive strength superior
5. Superior chemical resistance
6. Superior weather resistance
7. Good heat resistance
<Specifications & Colors>
Thickness(mm):3、4、5 、6,other specifications thickness can be customized.。
Size(Width x Length)( mm):1220x2440、1500x3000。
Color:Gery (730)
Note:The sheet stress relief surcharge.
<Applications>
1. 3-6mm: Pad dedicated
2. 13.2mm: Cutting board dedicated
<Property data sheet>
Test Method:ASTM D638-08;Modulus of Elasticity in Tension:14000↑
Test Method:ASTM D790;Modulus of Elasticity in Flexural:13500↑
Test Method:ASTM D638-08;Tensile Strength:250↑
Test Method:ASTM D638-08;Tensile Break Stress:150↑
Test Method: ASTM D638-08;Elongation at Break: 50↑
Test Method:ASTM D-648;Heat Deflection Temperature:90↑
Test Method:ASTM D-1525;Vicat Softening Temperature: 140↑
Test Method:ASTM D-256-93a;IZOD Un-notched 23℃ Impact Strength: 3↑
* Unit:kgf/cm2
