Telecommunications Batteries
| Item No.: | JBJPBA-4824 |
- LiFePO4 Battery 48V / 48AH containing a total of more than (group 2: 24A discharge 60 minutes, the cut-off voltage ≧ 40V)
- Batteries modules (including BMS) CE Compliance: EN61000-6-1: 2007, EN61000-6-3: 2007; batteries accord UL-1642
- 15 electrical batteries in series is 1 pack, each battery pack is not parallel with the number 1, all batteries use the same type of content
(1) High-pressure alarm: total voltage of 55.5V start alarm. Automatic discharge
alarm: less than 55.5V, more than 30sec
(2) Low Alarm: The total voltage 46V start alarm. Automatic discharge alarm: total
voltage 46V, more than 30sec or batteries voltage is below 2.2V (batteries fault).
(3) High temperature alarm: 65 ℃ start alarm. Automatic discharge alarm: temperature below 60 ℃, alarm eliminated.
(4) Over current alarm:
- (Charger charging current 20A) exceeds 30A start alarm. Automatic discharge alarm: Power up to 30A or less.
(1) The exception occurs when a single cell, the battery can not charge and discharge abnormality, and the rest work properly.
(2) Voltage protection: detection with single batteries for the units, with a total dry contact alarm detection voltage is different.
(2.1) when the single cell voltage is lower than 2.5V battery stops discharging rechargeable.
(2.2) when the single-cell voltage higher than 3.9V battery will not charge, can be discharged.
(3) High temperature protection: When the temperature exceeds 70 ℃ power protection,
the battery will not charge and discharge, when the temperature returns to below 60 ℃ recovery charge and discharge.
(4) Over-current protection: two battery section: 33A, power protection, has been
carried out; recovery charge and discharge current is detected again.
(5) When the battery pressure 4V, while still loaded with charging the normal power supply.
- power switch, LED signal lights (or other display capacity mode)
(1) after full charge LED is green 100%.
(2) lights from green to yellow 50%.
(3) lights from yellow to red light 10%.
2.
- Battery Case Material: Aluminum (thickness 1.6 mm or above).
- Nameplates in front of the battery case: both waterproof and dustproof
- processing.
- Battery total space dimensions (without handles): 400 * 150 * 380 mm (W × H × D) or less.
- cold swap mode (power supply connector and the connector at the rear of the
- socket engagement alarm).
- Front of a reserved power supply waterproof connector waterproof connector with alarm. (Provide link)
- Board shall have anti-corrosion treatment.
3. Product Specifications:
| Tender item | Mechanical Properties | |
| Model | JBJPBA-4824 | |
| 3.9 | Length | 380 mm |
| 3.9 | Width | 200 mm |
| 3.9 | Height | 150 mm |
| 3.9 | Weight | ≤20 kg |
| 3.7 | Casing Material | Aluminum (thickness 1.6㎜ or above) |
| 3.11 | Connector Type | Font: RJ-45(including dust sheet) : Dry-Contact SY50(including dust sheet) : Power Supply |
| 3.10 | Back: TE, Anderson High Current Connector | |
| 3.8 | IP Code | IP55 |
| Operating Conditions | ||
| Standard Charge Voltage | 54V±1V | |
| Standard Charge Current | 12A | |
| Max. Charge Current | 0.85C(20A±1 A) | |
| Max. Discharge Continuous Current | 1C(24A±1 A) | |
| Operating Temperature | ||
| Charge Temperature | 0~45℃ | |
| Discharge Temperature | -10~65℃ | |
| Storage Temperature | -10~45℃ | |
| Electrical Parameter | ||
| 3.1 | Nominal Voltage | 48 V |
| 3.1 | Nominal Capacity | 24 Ah |
| 3.3 | Cell Configuration | 15S12P |
| 3.6 | SOC | (1) 100% fully charged: LED is green |
| Certification | ||
| 3.2 | Cell safety | UL-1642 |
| System Alarm | ||
| 3.4.1 | High Voltage | 55.5 V start alarm. Automatic discharge alarm: less than 55.5V, more than 30sec |
| 3.4.2 | Low Voltage | 46 V start alarm. Automatic discharge alarm: the total voltage of 46V, more than 30sec or battery voltage is lower than 2.2V |
| 3.4.3 | Excess Current | 30A start alarm. Automatic discharge warning: current up to 30A or less |
| 3.4.4 | Excess Temperature | 65 ℃ start the alarm automatically released alarm: the temperature is below 60 ℃, the warning lifted |
| Cut Off | ||
| 3.5.2.1 | Over Voltage | Single cell voltage is below 2.5V battery stops discharging rechargeable. |
| 3.5.2.2 | Single-cell voltage higher than 3.9V battery will not charge may be discharged. | |
| 3.5.4 | Over Current | 33A power protection, recovery has been re-charge and discharge current detection. |
| 3.5.3 | Excess Temperature | The temperature exceeds 70 ℃ power protection, the battery can not be charged and discharged when the temperature returns below 60 ℃ recovery charge and discharge. |
| 3.5.1 | Pack protection | Single pack when an exception occurs, the exception can not pack charge and discharge, and the remaining work properly. |
4. Applications:
