Patented design Two-stage switch, low air consumption, quiet operation and low recoil shock. For PC chassis assembly.
A modular design for the complete tool series, vacuum system with an integrated design, high level of common parts for low spare parts inventory and easy maintenance
High setting force and low tool weight, faster working cycles, for each kind of process optimization tools.
Outstanding weight distribution, lightweight and durable ergonomically designed.
Low activation force trigger, have low recoil of shock-less, can reduce part of tools wear, and the can reduce operator is tired.
Set 3/16" and 3/32" structural Monobolt rivets, "T" rivets and standard rivets-in all materials.

Specifications

Country of Origin: Taiwan   Work Capacity: for setting standard rivets 2.4 ~ 4.8 mm (3/32 ~ 3/16 inch) in all materials       Stroke: 17 mm (0.94 inch)   Working Air Pressure: 85 ~ 95 PSI (6 –6.7 kg/cm2)   Traction Power: 2100 lbs (953.4kg)   Nosepieces: 3/16, 5/32, 1/8, 3/32 inch (4.8, 4.0, 3.2, 2.4 mm)   Vacuum: Yes   Tool Weight: 1.5 kg   Height: 270 mm   Length of Placing Head: 320 mm   Base Diameter: 90 mm   Safety/Quality Approvals: ISO9001; CE   Sales Method: Export, Manufacture, OEM/ODM
