Specification:

Free Slots	9
Power Source	AC 110V〜240V, 50/60Hz±10%
Max. Power Consumption	11W/AC 110V
Max. DC Output Power	150W
External Back-up Battery	24V/4 – 50AH
Max. Battery Charge Current	27. 6V/0.5A
CO + Station (Max.)	60
Station Capacity	8 – 56
CO Lines Capacity	4 – 32
Digital Key Telephone	8 – 56
Single Line Telephone	0 – 48
Switching System	PCM / TDM
Link Block	No Blocking
Tone Voice Source	Programmable Digital Voice Source
System Control	Stored Program Control
Speed Dialing (Max. 32 code) Number	System + Individual = 2000
Dimension (cm)	34.7 x 18 x 43
Net Basic Cabinet Weight (kg)	8
Available Temperature	5 – 45℃
Relative Humidity	20 – 80 %RH

Features:
■ Emergency Call button
All Uniphone systems are include the emergency button circuit that enable to install the emergency button on bathroom of hotel.
■ LCR (Least Cost Route)
LCR help the enterprise reduce the call-cost optimized - selecting the cheapest telecom carrier or the telecom discount time. 9 group 400 sets of LCR telephone number route perfect.
■ Built-In VoIP Interface (S/T) (Option)
Uniphone innovative built-in VoIP card is complete different from the gateway card -it occupied 1 slot capacity but not connect to FXO/FXS port. Select Trunk mode to register to ITSP for cost saving; select Station mode to connect with other branch offices (P2P (Pear to Pear) or register to same SIP proxy server) and the dialing way just similar to other extension.
■ Built-In ISDN-BRI Interface (S0/T0) (Option)
The ISDN-BRI interface can be connected with digital CO line (T0) or Station (S0), It also provides the ISDN supplementary service functions such as MSN/DDI,Caller ID, CLIP/R, COLP/R, En-Bloc,
Overlap, AOC.
■ Video/CCTV Compatible
Uniphone system enable to show the CCTV camera images if adopting USK 24TVHF.
