MPPT Solar Charge Controller
Item No.: | MS01 |
The charge Controller have been a vital component in a myriad of off-grid PV system. It’s prevent that over charge and over loading by battery, and extend the battery using life. Moreover, the some charge controller have advanced function, like lighting controller PLC control, remote monitoring…etc. The Morningstar charge controller has good quality with 2-5 warranty.
The characteristic for MPPT charge controller series
TriStar MPPT : Morningstar’s TriStar MPPT solar controller with TrakStar Technology™ is an advanced maximum power point tracking (MPPT) battery charger for off-grid photovoltaic (PV) systems up to 3kW
Morningstar’s TriStar MPPT 600V charge controller (TS-MPPT-600V) is a brand new addition to our world-leading TriStar MPPT solar controller family, which was first introduced in 2009 and has become the MPPT controller of choice for many large, global, off-grid PV applications.
SunSaver MPPT : Morningstar’s SunSaver MPPT™ solar controller with TrakStar™ Technology is an advanced maximum power point tracking (MPPT) battery charger for off-grid PV systems
Specification
MPPT CONTROLLERS |
MPPT: Maximum Power Point Tracking |
TriStar™ MPPT |
See ACCESSORIES for TS-MPPT: TS-M-2, TS-M-2-600V, TS-RM-2, GFPD, HUB-1, RD-1 |
TS-MPPT-45 |
TriStar MPPT 45 amp (12, 24, 36, or 48 volts), includes RTS |
TS-MPPT-60 |
TriStar MPPT 60 amp (12, 24, 36, or 48 volts), includes RTS |
TS-MPPT-60-600V-48 NEW! |
TriStar MPPT 60 amp (600V solar, for 48V battery) & standard conduit
box |
TS-MPPT-60-600V-48-DB NEW! |
TriStar MPPT 60 amp (600V solar, for 48V battery) & grounded Disconnect
Box |
SunSaver™ MPPT |
See ACCESSORIES for SS-MPPT: RM-1, HUB-1, RTS, DIN-1 |
SS-MPPT-15L |
SunSaver MPPT 15 amp (12/24 volts) |
