LCD Customer Display
Item No.: | DSP801 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 8F, No. 31 Lane 169, Kang-Ning Street, Hsi-Chih Dist
TEL: +886-2-26954214
Fax: +886-2-26954213

Online Showroom:
84 Products
Desktop LCD Customer Display
Introduction:
The DSP801 is a desktop customer display providing the configuration to integrated with the POS system for the pharmacy or the drugstores requiring basic privacy protection of customers. With the compacted and flat ID design in front of the sales counter or sales person passers by are not able to see the screen when viewed from the side. It offers privacy without easy to catch the text so the customers get more privacy environment in the shop site. It helps the retailing stores serve more customers with their shopping items which will be concerned more about some personal stuff, medical items… etc.
Features:
☆Supports OPOS drive
☆Desktop installation
☆Provides 2 in 1 benefit serving as a "Card send back tray" and displaying advertisement message
Applications:
≯POS Retailing shops
≯Pharmacy or drug store
≯The shops sell personal stuff requiring privacy
Specifications:
Ordering information:
·DSP801 USB interface
·DSP801 RS232 interface
※ Specification is subject to change without notice.

Introduction:
The DSP801 is a desktop customer display providing the configuration to integrated with the POS system for the pharmacy or the drugstores requiring basic privacy protection of customers. With the compacted and flat ID design in front of the sales counter or sales person passers by are not able to see the screen when viewed from the side. It offers privacy without easy to catch the text so the customers get more privacy environment in the shop site. It helps the retailing stores serve more customers with their shopping items which will be concerned more about some personal stuff, medical items… etc.
Features:
☆Supports OPOS drive
☆Desktop installation
☆Provides 2 in 1 benefit serving as a "Card send back tray" and displaying advertisement message
Applications:
≯POS Retailing shops
≯Pharmacy or drug store
≯The shops sell personal stuff requiring privacy
Specifications:
Display | LCD display |
Number of characters | 40 (20 columns x 2 lines) |
View area | 123 x 23 mm |
Active area | 118.84 x 18.97mm |
Dot size | 0.92 x 1.1mm |
Dot pitch | 0.98 x 1.16mm |
Character size | L4.84 x W 9.22mm |
Character pitch | L6.0 x W 9.75mm |
Power supply | 12V, 500mA |
Dimension | Display: H180 x W240 x D35 mm |
Interface | RS232 or USB |
Operating temperature | 0 ~ 55° C |
Ordering information:
·DSP801 USB interface
·DSP801 RS232 interface
※ Specification is subject to change without notice.
