Insertion Machines
| Item No.: | IP-08 |
Supplier Details
Country: Taiwan
City: NEW TAIPEI
Address: NO.8,LN.302,XINSHU RD.,XINZHUANG DIST.,NEW TAIPEI CITY 242,TAIWAN(R.O.C.)
TEL: +886-2-22060881
Fax: +886-2-22060800
Online Showroom:
33 Products
Technical Specifications:
Item NO.IP-08
Power Source: AC220V 1Phase 50Hz
Machine Dimension: 660 (L) x 660 (W) x 1900(H)mm
Weight: 105KGS
Air pressure: 6KGS/ c㎡
Pin diameter: 0.3-1.2 mm
Pin Length:35mm
Cycle time: 2.8sec./2pcs.
Pin Type: Round Square and flat pin
Number of Inserting Pin: 10Pins
Suitable products: Straight and L pin
OPTIONS: Bowl feeder Safety cover
Item NO.IP-08
Power Source: AC220V 1Phase 50Hz
Machine Dimension: 660 (L) x 660 (W) x 1900(H)mm
Weight: 105KGS
Air pressure: 6KGS/ c㎡
Pin diameter: 0.3-1.2 mm
Pin Length:35mm
Cycle time: 2.8sec./2pcs.
Pin Type: Round Square and flat pin
Number of Inserting Pin: 10Pins
Suitable products: Straight and L pin
OPTIONS: Bowl feeder Safety cover
