Acrylic Conformal Coating

Item No.:

CE-1171

Supplier Details

Country: Taiwan

City: Taichung City 428017

Address: No. 12-1, Qiancun E. Rd., Daya Dist.

TEL: +886-4-25685848

Fax: +886-4-25685857

Online Showroom: 103 Products

Product Description

CONAP® CE-1171 is a transparent, solvent- based, fast-curing, single-component acrylic conformal coating.

Areas of Application

CONAP® CE-1171 provides an excellent electrical and moisture barrier for thin film applications on components and printed circuit boards.

Features and Benefits

QPL Listed for MIL-I-46058C for Type AR
IPC-CC-830B
Halogen-free (IEC 61249-2-21)
Excellent hydrolytic stability
UL94 V-0
Flexible coating
Excellent adhesion to phenolic and epoxy-glass laminates; even in harsh environments
Excellent reparability
Tracer dye for inspection under UV lighting

Application Methods

Transportation / Storage

Store at or below 25°C / 77°F in a dry controlled environment out of direct sunlight. This material should be suitable for use stored under these conditions in the original sealed containers for twelve (12) months from the date of shipment.
This product is sensitive to moisture and atmospheric humidity. Containers, once opened, should be used immediately or blanketed with dry air or nitrogen (CONAP® Dri-Purge) before resealing.
Failure to store the product as recommended above may lead to deterioration in product performance.

Health / Safety

CAUTION: Material is flammable. Do NOT use in the presence of open flames or sparks.
Refer to the Safety Data Sheet.
