Aluminium Alloy 2024
| Item No.: | 2xxx 7xxx High Strength Aluminum Alloy |
Supplier Details
Country: Taiwan
City: Tainan City 710, Taiwan
Address: No.28, Xinggong Rd., Yongkang Dist.
TEL: +886-6-2335308
Fax: +886-6-2326904
Online Showroom:
31 Products
Aluminum Angle Bar
Dimensions: mm (Millimeter)
OD=Out Side Diameter
t=Wall Thickness
Extrusion --OD: Cross section Area: 100mm2~2500mm2 Following by EN 755, ASTM B221M
2xxx series alloy, one of the best known high-strength aluminum alloys, with excellent fatigue resistance. Used in structures and parts where good strength-to-weight properties are desired. Corrosion resistance is relatively low, so 2024 angle bar is often clad (Alclad) to improve upon this detail. This alloy can be formed in the annealed condition and then subsequently heat-treated.
7xxx series alloy angle bar is one of the highest strength aluminum alloys available. It is ideally used in highly stressed parts. In sheet it is also available as Alclad to improve corrosion resistance. Often used in aerospace applications because of its desirable mechanical properties. May be formed in the annealed condition and then heat-treated.
Inquiries are welcome.
The Max. Length of heat-treating and stress relief product is 160 inches / 4050 mm
Dimensions: mm (Millimeter)
OD=Out Side Diameter
t=Wall Thickness
Extrusion --OD: Cross section Area: 100mm2~2500mm2 Following by EN 755, ASTM B221M
- Material: 2014, 2017,2024, 7005, 7010, 7050, 7075, 7175
- Temper: F, O, T3, T4, T5, T6, T651, T7x, T7x511 or T7x510
- Type: Extrusion
- Application: Aero Space, Automobile, Motorcycle/Scooter, Bike, Safety Product
- Products: Aircraft Structural Components, Aircraft Fittings, Hardware, Parts for The Transportation Industry
- Prompt delivery time: 30~40 working days (depends on the difficulty of procedure and mfg process lead time)
- Sizes and designs are all customize
- Origin: Taiwan
2xxx series alloy, one of the best known high-strength aluminum alloys, with excellent fatigue resistance. Used in structures and parts where good strength-to-weight properties are desired. Corrosion resistance is relatively low, so 2024 angle bar is often clad (Alclad) to improve upon this detail. This alloy can be formed in the annealed condition and then subsequently heat-treated.
7xxx series alloy angle bar is one of the highest strength aluminum alloys available. It is ideally used in highly stressed parts. In sheet it is also available as Alclad to improve corrosion resistance. Often used in aerospace applications because of its desirable mechanical properties. May be formed in the annealed condition and then heat-treated.
Inquiries are welcome.
The Max. Length of heat-treating and stress relief product is 160 inches / 4050 mm
