high frequency pvc welding equipment
| Item No.: | JGP- 4T 5T 6T 8T 12T 15T/ZRG |
Supplier Details
Country: China
City: Xiamen
Address: No. 3 Plant, No. 39 Xiayang Road, Xinyang Industrial Zone, Haicang District
TEL: +86-592-5581299
Fax: +--
Online Showroom:
30 Products
H. F. plastic welding machine with pressurization & electric heating & high sensitivity spark protection
1. High frequency Plastic Welding machine
2. Pressurization function is almost the same as hydraulic, but very clean. 3. Electric heating improves production efficiency. 4. High sensitivity spark protection protects products & moulds. Description: 1. This kind machine has high cost-performance, very suitable for shoes & leather & raincoat etc. processing. 2. Its pressurization function has powerful pressure and keep the working station very clean, so its application is wider than traditional hydraulic type machine. Specification: Product Name H.F.PLastic Welding Machine with pressurization & electric heating etc. Model JGP-5T/ZRG JGP-6T/ZRG JGP-8T/ZRG JGP-12T/ZRG JGP-15T/ZRG H.F. Output Power 5KW 6KW 8KW 12KW 15KW Voltage 1ΦAC220V or 3ΦAC380V 3ΦAC380V or 3ΦAC220V Power Input 8KVA 10KVA 15KVA 20KVA 25KVA Oscillation Frequency 40.68MHZ 27.12MHZ 20~27.12MHZ Oscillation Tube 7T85RB 7T69RB/E3069 7T69RB/E3069 8T85RB 8T85RB Electrode Size(mm) 300×650 300×650 350×700 350×700 350×700 Working Stroke(mm) 60 Profile Size(mm) 1550×1140×2200 1550×1140×2200 1740×1190×2230 1740×1190×2230 1740×1190×2230 Net Weight 300kg 385kg 450kg 480kg 500kg NOTE: We will improve design continuously, so no prior notice for any design changement.
2. Pressurization function is almost the same as hydraulic, but very clean. 3. Electric heating improves production efficiency. 4. High sensitivity spark protection protects products & moulds. Description: 1. This kind machine has high cost-performance, very suitable for shoes & leather & raincoat etc. processing. 2. Its pressurization function has powerful pressure and keep the working station very clean, so its application is wider than traditional hydraulic type machine. Specification: Product Name H.F.PLastic Welding Machine with pressurization & electric heating etc. Model JGP-5T/ZRG JGP-6T/ZRG JGP-8T/ZRG JGP-12T/ZRG JGP-15T/ZRG H.F. Output Power 5KW 6KW 8KW 12KW 15KW Voltage 1ΦAC220V or 3ΦAC380V 3ΦAC380V or 3ΦAC220V Power Input 8KVA 10KVA 15KVA 20KVA 25KVA Oscillation Frequency 40.68MHZ 27.12MHZ 20~27.12MHZ Oscillation Tube 7T85RB 7T69RB/E3069 7T69RB/E3069 8T85RB 8T85RB Electrode Size(mm) 300×650 300×650 350×700 350×700 350×700 Working Stroke(mm) 60 Profile Size(mm) 1550×1140×2200 1550×1140×2200 1740×1190×2230 1740×1190×2230 1740×1190×2230 Net Weight 300kg 385kg 450kg 480kg 500kg NOTE: We will improve design continuously, so no prior notice for any design changement.
