Hard coating resin-RSR-100-Q9 - RSR-100-Q9

Hard coating resin-RSR-100-Q9

Item No.: RSR-100-Q9
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom: 68 Products
■ Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Clear yellow
4.Solid content: approach 100%
5.Viscosity (26 ℃): 320 ± 80 cps
6.Liquid refractive index: 1.54 ± 0.005
7.Resin gravity g: 1.12 / cm3
8.The glass transition temperature (Tg): -18 ℃
■  Hardening conditions
1. The resin-coated at a thickness of 30μm, it is recommended UV accumulated energy greater than 350 mj / cm2.
2. It is recommended to use a solvent: MEK
3. Recommended operating temperature: 70,75,80,75 ℃, the production rate: less than 12M / min
■ Finished nature (Mitsubishi O321E 125 μm PET)
1.Coating thickness: 30μm (dry film thickness)
2.Haze: less than 1.0%
3.100 grid knives (after molding): 5B
■ Features
1. UV molded surface after a review of the self-study.
2. hardened surface low yield, not to damage the substrate.
3. Has the strength and toughness, pulling prone to breaking
