Hard coating resin-RSH-P2015-BL
| Item No.: | RSH-P2015-BL |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Product Features
1. excellent optical properties, good transparency.
2. Anti Blu-ray feature is excellent, money detector pen irradiation does not penetrate.
3. UV wavelength of 365nm is irradiated for about 12 seconds (cumulative energy of approximately 250 ~ 300 mj / cm2).
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Transparent with yellow mouth
4.Solid content: approach 28%
5.Viscosity (19 ℃): 20 cps or less
6.Resin gravity: 1.12 g / cm3
■ Hardening conditions
1. It is recommended to add solvents: Toluene: MEK: EAC = 6: 3: 1, can decrease the viscosity, ease of processing applied.
2. It is recommended baking temperature: 70 ~ 75 ℃ lasted about 45 seconds or more.
■ Finished nature (Optical 100 μm primer PET)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Haze: 2.0% ↓
3.Penetration: 89% ↑
4.Pencil Hardness (weight 765g): 3H
5.100 grid knives (after molding): 5B
6.100 grid knives (ring measured after 500 hours **): 5B
1. excellent optical properties, good transparency.
2. Anti Blu-ray feature is excellent, money detector pen irradiation does not penetrate.
3. UV wavelength of 365nm is irradiated for about 12 seconds (cumulative energy of approximately 250 ~ 300 mj / cm2).
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Transparent with yellow mouth
4.Solid content: approach 28%
5.Viscosity (19 ℃): 20 cps or less
6.Resin gravity: 1.12 g / cm3
■ Hardening conditions
1. It is recommended to add solvents: Toluene: MEK: EAC = 6: 3: 1, can decrease the viscosity, ease of processing applied.
2. It is recommended baking temperature: 70 ~ 75 ℃ lasted about 45 seconds or more.
■ Finished nature (Optical 100 μm primer PET)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Haze: 2.0% ↓
3.Penetration: 89% ↑
4.Pencil Hardness (weight 765g): 3H
5.100 grid knives (after molding): 5B
6.100 grid knives (ring measured after 500 hours **): 5B
