Hard coating resin-RSH-100-D8-B-P2007
| Item No.: | RSH-100-D8-B-P2007 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Product Features
1. The optical transmittance resistance.
2. Suitable for Embossing process, good surface hardness after molding.
3. Suitable for LED UV lamp manufacturing process, forming speed can exceed 20 M / min.
■ Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: pale transparent
4.Solid content: approach 100%
5.Viscosity (25 ℃): 250 ± 30 cps
6.Specific gravity: 1.06 ± 0.05
7.A glass transition temperature (Tg): approach 96 ℃ (calculated value)
■ Curing conditions
1. It is recommended to use a solvent-free coating process.
Under the irradiation energy accumulated to 500 ~ 750 mj / cm2 of ultraviolet light curing source
2. wavelength of about 390 nm, the non-exposed to the air for curing.
■ Finished properties (Sunbeam C87H 100μm PET)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Pencil Hardness (weight 500g): appach 3H
3.Water absorption: TBD
4.Thermal expansion coefficient:> 60 ppm / ℃
5.100 grid knives (after molding): 5B
