Hard coating resin-RSH-050-IMD2-E
| Item No.: | RSH-050-IMD2-E |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Features
1. before and after thermal UV belong process, there will be no cracking problem after punching.
2. Low rainbow pattern, then print resistance.
3. B value is low (less than 0.8), there will be yellow and appearance change issues.
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: light yellow transparent
4.Solid content: approach 60%
5.Viscosity @ 25 ℃: 270 ± 30 cps
6.A glass transition temperature (Tg): 76 ℃ (calculated value)
■ Hardening conditions
1. It is recommended to add solvents: toluene or EAC, so viscosity decreased, ease of processing applied
2. It is recommended baking temperature: 100 ~ 105 ℃ lasted about 120 seconds.
3. punching or embossing is completed, and then irradiated with UV wavelength of 365nm to about 14 to 15 seconds (cumulative energy of about 400 mj / cm²)
■ products (Bayer PC DE-1 178μm)
1.Coating thickness *: 6 ~ 8μm (dry film thickness)
2.Etiolated (yellowness index): TBD
3.Pencil Hardness (weight 765g): H ~ 2H
4.Printability: Pass
5.100 grid knives (after molding): 5B
6.100 grid knives (ring measured after 500 hours **): 5B
