■ Product Features
1. Good maneuverability, low-energy UV light to cure.
2. High penetration, excellent optical properties.
3. Good adhesion, after forming material does not fall off.
4. After UV molding, surface up factor is low, easy to wipe clean easily.


■ Resin Specifications
Chemical Composition: Acrylic resin
Physical Status: Fluid @ 25 ℃
Appearance: Clear yellow
Solid content :: 50 ± 2%
Viscosity (26 ℃): 30 cps ↓
Liquid refractive index (29 ℃): 1.47 ± 0.005
Resin gravity: 1.11 ± 0.05 g / cm3

■  Hardening conditions
Under the irradiation energy accumulated to 300 ~ 350 mj / cm2 hardening 1. Mercury H lamp at a wavelength of about 365 nm UV light source, the non-exposed to the air, and cured.

■ Finished properties (Mitsubishi O321E PET film)
Coating thickness: 5 ~ 6μm (dry film thickness)
Penetration (400 ~ 700nm): 91.2% ↑
Pencil Hardness (weight 500g): 2 ~ 3H
Abrasion (steel wool # 0000): Pass
Surface up factor: 32 dyne / cm2 ↓
100 grid knives (after molding): 5B
