Hard coating resin-RES-W039-005
| Item No.: | RES-W039-005 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Features
1. suitable for use emboss molding.
2. good adhesion, fold does not fall off.
3.After UV molding, excellent optical properties.
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.The physical state of the fluid: @ 25 ℃
3.Appearance: Clear clarification
4.Solid content: approach 100%
5.Viscosity (25 ℃): 230 ± 50 cps
6.Resin gravity: 1.03 g / cm3
7.Refractive index: 1.478 ± 0.005
■ Hardening conditions
1. wheel Recommended temperature: 35 ~ 45 ℃ continued; UV cumulative energy: 280 ~ 350mj / cm2.
■ Finished properties (Sunbeam C87H PET film)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Haze: 2%
3.Pencil Hardness (weight 765g): 2H ↑
4.Water absorption%: TBD
5.100 grid knives (after molding) 5B
1. suitable for use emboss molding.
2. good adhesion, fold does not fall off.
3.After UV molding, excellent optical properties.
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.The physical state of the fluid: @ 25 ℃
3.Appearance: Clear clarification
4.Solid content: approach 100%
5.Viscosity (25 ℃): 230 ± 50 cps
6.Resin gravity: 1.03 g / cm3
7.Refractive index: 1.478 ± 0.005
■ Hardening conditions
1. wheel Recommended temperature: 35 ~ 45 ℃ continued; UV cumulative energy: 280 ~ 350mj / cm2.
■ Finished properties (Sunbeam C87H PET film)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Haze: 2%
3.Pencil Hardness (weight 765g): 2H ↑
4.Water absorption%: TBD
5.100 grid knives (after molding) 5B
