Hard coating resin-RES-W031-006
| Item No.: | RES-W031-006 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Features
1. excellent optical properties.
2. The surface is smooth, singular pen is not easy to write.
3. The water contact angle is large, dirty easy attachment.
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.The physical state of the fluid: @ 25 ℃
3.Appearance: Clear clarification
4.Solid content: approach 50%
5.Viscosity (26 ℃): 10 cps or less
6.Dilution solvent: MEK
7.A glass transition temperature (Tg): 98 ℃ (calculated value)
■ Hardening conditions
1. The oven temperature (four): 60,65,70,60 ℃ lasted about 45 sec; UV cumulative energy: 250 ~ 300mj / cm²
■ Finished properties (Sunbeam C87H primer 100 μPET)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Pencil Hardness (weight 765g): 3H ↑
3.Water absorption%: TBD
4.100 grid knives (after molding): 5B
