Hard coating resin-RES-E044-007
| Item No.: | RES-E044-007 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Features
1. PET substrate with good adhesion.
Excellent optical properties after
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Clear clarification
4.Solid content: approach 99%
5.Viscosity (26 ℃): 400 ± 80 cps
6.Liquid refractive index: 1.5 ± 0.05
7.Resin gravity: 1.1 g / cm3
8.A glass transition temperature (Tg): 102 ℃
■ Curing conditions
1. The oven temperature (four): 80,90,95,90 ℃ lasting about 30 sec; UV cumulative energy: 250 ~ 300mj / cm²
■ Finished properties (Sunbeam C87H 100 μm PET film)
Coating thickness: 2 ~ 3μm (dry film thickness)
Pencil Hardness (weight 765g): 2H
Water absorption: TBD
100 grid knives (after molding): 5B
