Solder Machines
| Item No.: | ETS-2MT |
Supplier Details
Country: Taiwan
City: NEW TAIPEI
Address: NO.8,LN.302,XINSHU RD.,XINZHUANG DIST.,NEW TAIPEI CITY 242,TAIWAN(R.O.C.)
TEL: +886-2-22060881
Fax: +886-2-22060800
Online Showroom:
33 Products
Technical Specifications:
Item NO.ETS-2MT
Soldering way: Jig up/down
Power source: AC220V 2000W
Machine dimension: 500(L) x 850 (W) x 660(H)mm
Weight / Air pressure: 75KGS/5kgs/cm2
Inner pot size: 295(L) x 105 (W) x 65(H)mm
Cycle time: 10-20 pcs / 10-12sec
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: any coil
Dip cup up/down distance: 76mm (Controlled by Cylinder)
OPTIONS:
Features:
Item NO.ETS-2MT
Soldering way: Jig up/down
Power source: AC220V 2000W
Machine dimension: 500(L) x 850 (W) x 660(H)mm
Weight / Air pressure: 75KGS/5kgs/cm2
Inner pot size: 295(L) x 105 (W) x 65(H)mm
Cycle time: 10-20 pcs / 10-12sec
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: any coil
Dip cup up/down distance: 76mm (Controlled by Cylinder)
OPTIONS:
- Dip flux automatically
- Feed solder automatically
- Leave solder dross after dip solder
- Servo motor control, Dip cup up down
Features:
- Automatic Soldering pot Flux Clean
- Soldering pot Automatic Temperature Control
- Soldering Quality control
- Soldering Time Control
- Soldering Speed Control
