Machine Soldering
| Item No.: | EDT-6 |
Supplier Details
Country: Taiwan
City: NEW TAIPEI
Address: NO.8,LN.302,XINSHU RD.,XINZHUANG DIST.,NEW TAIPEI CITY 242,TAIWAN(R.O.C.)
TEL: +886-2-22060881
Fax: +886-2-22060800
Online Showroom:
33 Products
Technical Specifications:
Item NO.EDT-6
6 Station Soldering Machine
Power source: AC220V 1300W
Machine dimension: 1200(L) x 1200 (W) x 1400(H)mm
Weight / Air pressure: 300KGS/5kgs/cm²
Inner pot size: 155(L) x 110 (W) x 65(H)mm
Cycle time: 2.0 sec/pc.
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: Transformer、Relay and Fan motor
OPTIONS:
Process: Load -> Flux -> Solder -> Press(bend pin) -> Test -> Unload (Automatic loading / unloading through conveyor)
Features:
Item NO.EDT-6
6 Station Soldering Machine
Power source: AC220V 1300W
Machine dimension: 1200(L) x 1200 (W) x 1400(H)mm
Weight / Air pressure: 300KGS/5kgs/cm²
Inner pot size: 155(L) x 110 (W) x 65(H)mm
Cycle time: 2.0 sec/pc.
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: Transformer、Relay and Fan motor
OPTIONS:
- Solder cup up/down control by stepping or servo motor
- Ohm Test
- Wave solder
- Flux density control
- Tin feeder
- Unload coil to belt
Process: Load -> Flux -> Solder -> Press(bend pin) -> Test -> Unload (Automatic loading / unloading through conveyor)
Features:
- Any pin type of bobbins can be adjusted more easiley and exactly.
- Automatically clean the sediment before solder.
- The height of Soldering can be adjusted exactly.
- Soldering time can be set.
- Heating pipe is moveable, easy to be installed.
