Superior linearity
Application to both AC and DC measurement
Compact size and light weight
Quick response
Providing absolute electrical isolation

Specifications：
Offset (Residual) Voltage：±0.03V
Linearity of Rated Output Voltage：± 1%
Power Supply：±15V
Consumption Current：18mA
Response Time：10 u sec
Thermal Drift of Output：TYP. ±0.08% / ℃, Max. ±0.1% / ℃
Thermal Drift of Zero Current Offset：±2mV / ℃, ±1.2mV / ℃, ±1mV / ℃
Hysteresis Error：±0.035V
Insulation Resistance：Over 500MΩ between aperture and terminals
Applied Voltage Test：2000V, 50 / 60Hz between aperture and terminals

Applications：
UPS systems
AC and DC servo systems
Speed controller of motors
NC tooling machines
Inverter-controlled welding machines
Controller of lifts
Controller of electrical vehicles
Process control devices
General and special purpose inverters
Other automatic control systems

Dimension / Weight：
38(L) x 28(W) x 18 (H)mm
Approx. 50g
Aperture size: 20 x 10mm

TEMP./Humidity：
Operation：-10°C~ 80°C/ <80% R.H.(no condensation)
Storage：-15°C~ 85°C/ <70%R.H.(no condensation)
