Circular Saw Blade Installation
| Item No.: | Saw Installation |
Supplier Details
Country: Taiwan
City: Tainan City 709
Address: 1F., No. 176, Le'an 2nd St., Annan Dist.
TEL: +886-6-2470899
Fax: +886-6-2473899
Online Showroom:
34 Products
Saw Installation
YAMAOO TECHNICAL DATA
Cutting material applicable cycle speed table
Limit table of rotation number
- Ensure the sawblade turns in the same direction as the spindle does. Lf not, accidents are likely to occur.
- Choose the flange whose inner diameter is the same as that of the sawblade but the outer diameter is a little larger than 1/3 (for multi-rip sawblade is 1/2) of the sawblade. Ensure the flange is clean, not over worn, bent and distorted shape.
- Check the tolerance between the sawblade and the spindle. Install the flange and fasten the screw.
- Be sure no people stand in front of the machine when starting the machine. Do not feed, just to check whether there is any vibration, radial or axial run out.
- Sawblade reprocessing such as bore trimming or reboring, should be finished by the factory. Poor reprocessing would lead to poor quality and may cause injuries.
- While installation, the sawblade should be 5-6 teeth higher than the board surface.
