Autofocus CCD

Item No.:

ME10

Supplier Details

www.microscope-camera-manufacturer.com

Country: China

City:

Address:

TEL: +--

Fax: +--

Online Showroom: 41 Products

Product Details Supplier Profile

With a high-resolution, automatic focus, color fidelity, image clarity and other characteristics, MSHOT autofocus CCD ME10 can realize real-time preview, capture and magnify image from computer. Simple operation make your work faster than before. MSHOT autofocus CCD ME10 is the ideal filming equipment to electronics, precision machinery, automobile, metal, medicine, chemistry, printing, identification, education, and other industries.

ME10 Features:

◆ Pioneer auto-focus digital imaging devices in China

◆ Upgrade for antique identification, security testing, industrial maintenance, etc.

◆ 2 million dynamic pixels, 5 million static pixels.

◆ USB2.0 interface realize high-definition image sharing.

◆ Multi-stage amplification, up to 180X..

◆ Image preview, storage and measurement directly in computer.

◆ Minimum working distance 5cm, large DOF.

◆ Compact and flexible structure, applicable to laboratory console, production lines etc.

Real shot pictures:

Specification:

Sensor	1/ 2.3〞color
Pixel size	2.2 um X 2.2 um
Spectral response	400 nm ~ 1000nm
Sensitivity	0.6 V/Lux-sec
Scan mode	Progressive scanning
Resolution	640 X 480 , 800 X 600 , 1280 X 960 , 1600 X 1200
White balance	Manual/Auto one-touch
Exposure control	Manual/Auto one-touch
Interface	USB2.0
Power Supply	USB2.0
Dynamic Range	50DB
Programmable control	Image size, quality, brightness, gain, exposure time, contrast, saturation, sharpness
Operating Tem	0-50℃

Applications:

Electronic and precision machinery

With large DOF and multi-angle observation structure,ME10 makes electronic and precision machinery products observation become easy. Ultra-long working distance allows convenient detection of large thickness parts too.

Automotive and metal

Hand-hold option can save time and improve work efficiency, especially when ME10 is used to observe uneven surfaces.

Medical and chemical

Traditional microscope need many times of focusing,when observe uneven surfaces. But ME10 just need one time.

Printing and identification

High-resolution, high cost-effective and convenient operation features are very suitable to identify print quality, handwriting, jewelry and antiques etc.

Education

ME10 is an idea device for teaching demonstration and experiment Not only develop children's interest in science and the practical ability, ME10 can also enrich teaching methods and enhance students interest in learning and efficiency.
