Anti-fingerprint-RSH-P2018
| Item No.: | RSH-P2018 |
Supplier Details
Country: Taiwan
City: New Taipei City
Address: 7F., NO.3, GUIFENG ST., TAISHAN DIST., NEW TAIPEI CITY 24355, TAIWAN (R.O.C.)
TEL: +886-2-29010509
Fax: +886-2-29014616
Online Showroom:
68 Products
■ Features
1. excellent optical properties, good transparency.
2. hardened surface with anti-fingerprint properties, poor adhesion to the front to watch the fingerprint, and easy to clean.
3. UV wavelength of 365nm is irradiated for about 12 seconds (cumulative energy of approximately 250 ~ 300 mj / cm2).
■ Resin Specifications
1.Chemical Composition: Acrylic resin
2.Physical Status: Fluid @ 25 ℃
3.Appearance: Clear yellow
4.Solid content: approach 25%
5.Viscosity (19 ℃): 20 cps or less
6.A glass transition temperature (Tg): 68 ℃
■ Hardening conditions
1. It is recommended to add solvents: Toluene: MEK: EAC = 6: 3: 1, can decrease the viscosity, ease of processing applied.
2. It is recommended baking temperature: 70 ~ 75 ℃ lasted about 45 seconds or more.
3. UV irradiation wavelength of 365nm to about 12 seconds (cumulative energy of about 250 ~ 300 mj / cm²).
■ Finished nature (Mitsubishi Optical 100 μm PET)
1.Coating thickness: 5 ~ 6μm (dry film thickness)
2.Haze%: 0.5
3.Pencil Hardness (weight 765g): 2 ~ 3H
4.100 grid knives (after molding): 5B
