Air Dry Varnish
| Item No.: | B-277-2 |
Supplier Details
Country: Taiwan
City: Taichung City 428017
Address: No. 12-1, Qiancun E. Rd., Daya Dist.
TEL: +886-4-25685848
Fax: +886-4-25685857
Online Showroom:
103 Products
Product Description
Elantas Zhuhai B-277-2 is a solvented, alkyd resin based, air-drying, up to class ‘180°C’ varnish with excellent electrical properties, good tank stability and anti-tracking qualities and incorporating a “user friendly” fungicide.
B-277-2 gives a bright surface finish, excellent protection against leakage currents and is particularly useful for protecting metal surfaces against oxidation.
B-277-2 is an ideal impregnant for small transformers and coils where a rapid air-drying film is required. This product is not recommended for the impregnation of deep section windings.
B-277-2 is compatible with most insulation systems, has good chemical and water resistance, has a thermal ratings from 130°C to 180°C and is UL listed under the Underwriters Laboratories OBOR2 File E314793 volume 3.
Areas of Application
The preferred applications for B-277-2 series are via conventional dip and bake application for:
Stators
Transformers
Coils
Please note that this product is not recommended for the impregnation of deep section windings.
Processing
B-277-2 is generally suitable for impregnating components at ambient temperatures. Coated components can, however, be forced dried at elevated temperatures up to a maximum of 110°C.
Cure characteristics
25°C 60-120 minutes
110°C 25-35 minutes
It is essential to ensure that tanks and containers of B-277-2 remain sealed or well covered to minimise solvent loss and retain storage stability.
The viscosity of B-277-2 should be monitored regularly with reference to the Viscosity - graphical representations are available upon request.
Elantas Zhuhai X2 or S002 are the recommended solvents for viscosity modification purposes and is available from Elantas Zhuhai. Thinning with other low cost solvents can be performed following suitability analysis by the ELANTAS Zhuhai technical service department.
Packaging
B-277-2 is currently sold in 15kg & 160kg containers for ease of use.
Health & Safety
Refer to Elantas Zhuhai Material Safety Data Sheet (MSDS) for B-277-2.
Shelf life
12 months (in unopened containers stored under 25°C).
