Insertion Equipment
| Item No.: | AIP-02 |
Supplier Details
Country: Taiwan
City: NEW TAIPEI
Address: NO.8,LN.302,XINSHU RD.,XINZHUANG DIST.,NEW TAIPEI CITY 242,TAIWAN(R.O.C.)
TEL: +886-2-22060881
Fax: +886-2-22060800
Online Showroom:
33 Products
Technical Specifications:
Item NO.AIP-02
Power Source: AC220V 1Phase 50Hz
Machine Dimension: 660 (L) x 660 (W) x 1900(H)mm
Weight: 550KGS
Air pressure: 6KGS/ c㎡
Pin diameter: 0.4-0.5 mm
Pin Length: 30mm
Cycle time: 2.5sec./1pcs.
Pin Type: Round pin
Number of Inserting Pin: 2 Pins
Suitable products: Straight and L pin
OPTIONS: Bowl feeder Safety cover
Item NO.AIP-02
Power Source: AC220V 1Phase 50Hz
Machine Dimension: 660 (L) x 660 (W) x 1900(H)mm
Weight: 550KGS
Air pressure: 6KGS/ c㎡
Pin diameter: 0.4-0.5 mm
Pin Length: 30mm
Cycle time: 2.5sec./1pcs.
Pin Type: Round pin
Number of Inserting Pin: 2 Pins
Suitable products: Straight and L pin
OPTIONS: Bowl feeder Safety cover
