Φ9*18mm Infrared structured light laser module
| Item No.: | HT-006090180 |
Supplier Details
Country: Taiwan
City: Tainan City
Address: No. 239-8, Yanxing Rd., Yongkang Dist., Tainan City 710, Taiwan (R.O.C.)
TEL: +886-6-2432668
Fax: +--
Online Showroom:
30 Products
Shape size：Φ9mm*18mm （Custom-made by customers）
Wavelength：940nm
Output power：200mW（Custom-made by customers）
Operating voltage ：DC 1.8~2.4V（Custom-made by customers）
Operating current：270~320mA （Custom-made by customers）
Operating temperature：-10~60℃
Storage temperature: -40~85℃ DOE FOV：60x46.8/70 x 55.4/80x 50.5 deg. DOE point：15000 / 30000 dot
Wavelength：940nm
Output power：200mW（Custom-made by customers）
Operating voltage ：DC 1.8~2.4V（Custom-made by customers）
Operating current：270~320mA （Custom-made by customers）
Operating temperature：-10~60℃
Storage temperature: -40~85℃ DOE FOV：60x46.8/70 x 55.4/80x 50.5 deg. DOE point：15000 / 30000 dot
