Printable for large size
The diameter of the chassis is18 cm. The height of production can be20 cm. Using the least desk space to create maximum production efficiency.

Automatic correction
Introducing an innovative nozzle auto-correction feature, which ensures the accuracy of every production.

Multiple choices of the color
EC-5 has 4 basic colors for the outer casing, and the color can also be customized based on the need.

Simple and smart
Every aspect and every detail have been designed, validated, and modified again and again.

Specifications
Physical Dimensions
Outline dimensions: 500 (W) x 600 (D) x 850 (H) mm
Material coil: available for any brands
Weight:12 kg

Software
Software included: Repetier Host, Kisslicer, and Cura
Compatible 3D files: STL, OBJ, and GCODE
Compatibility: Windows XP and above; Mac OSX 10.6 and above

Temperature
Working temperature: Room temperature
Storage temperature: 0-35℃
PLA temperature: 180~190℃
Heating time under 20-300 ℃: 60~90 seconds



Printing
Printing technology: FFF (Fused Filament Fabrication)
Build volume: Φ30 x 35 cm
Layer thickness: min 0.05 mm/ max 0.3 mm
Material: Φ1.75 mm PLA
Maximum speed: print 100 mm/s , move 200 mm/s


Mechanical
Structure: 2020 aluminum extrusion
Main parts: 3D print PLA
Print platform: glass
Stepper motors: NEMA17 1.8° step angle, 1/16 micro-stepping


Electrical
AC power: 100-240V
Electricity demand: 12V DC @ 5 amps
Connectivity:USB,SDcard
