Name:             10 nozzles Inverter Fog Machine
Item No.:         TT10024
Nozzle:            10 pcs ∮0.2mm nozzles
Motor:             TT80024, DC Brushless
Voltage:           24 V
Inner Box:        350(L)*350(W)*150(H)mm/0.65’/2.8KGS/set
Carton size:       360(L)*650(W)*370(H)mm/3.1’/14.0KGS/4sets
Weight:            2.8 KGS/set

AC Adapter
Input:              Universal 100 ~ 240 V，single phase
Frequency:        50 ~ 60 Hz
Current:            1.4A Max.
Inrush Current:   80A Max./240Vac (Cold Start at 25℃，Full Load)
                       Pi<=0.5W(At 230V & No Load)  w/o any slide switch
Output:             +24V ± 5%
                       2.71A Max.( Peak Io = 11A/0.1mSec Max.，can provide continual use for 30 sec.)
                       Ripple & Noise: 240mV Max.
Case Dimension: 115(L) * 53(W) * 38(H)mm
Efficiency:         Eff(av)=>87%(At 115 Vac & 230 Vac)
Safety:              UL/cUL/GS/PSE/BSMI/CB/RCM
EMI:                 CE/FCC   Class B; Conduction & Radiation Met.
Protection:        OVP: V out (110% ~ 150%)
                       SCP (Automatic recovery after short-circuit fault being removed)
                       High frequency design，less power consumption.
                       Meet DoE/ErP(Stage 2)/MEPS V/NRCan
Total Power:      65 Walt Max.(Peak 264W Max.)
Environment Performance:
Temperature:     Operating: 0℃ ~ +40℃
                       Storage:-20℃ ~ +80℃
Humidity:          Operating: 20%  ~  80% RH
                       Storage:    10%  ~  90% RH
M.T.B.F.:           50,000Hrs.(At25℃ ， By MIL-HDBK-217F)
Weight:            280g Typical
Cable Type:       Black UL1185 16AWG(Wire + Plug)
                       Plug:ψ5.5*ψ2.5*9.5mm(Tuning Fork & Cannelure)
Cable Length:    1500mm
